Specifications

Note: Maximum transfer speed recorded

* 25 °C , test on GA-Z87Z-UD3H, 4GB, Windows

8.1 x64 with AHCI mode, benchmark utility CrystalDiskMark (version 3.0.1), copied file 1000MB

** Random read/write performance based on IOmeter2008 with 4K file size and queue depth of 32

*** The recorded performance is obtained while the SSD is not operating as an OS disk

Physical Specification

Form Factor

MO-300B

Storage Capacities

128GB

Dimensions

Length

26.8  0.15 mm

Width

29.85  0.15 mm

Height

3.85 mm (Max)

Input Voltage

3.3V  5%

Weight

Connector

PCI Express Mini Card Connector

Environmental Specifications

Operating Temperature

0 ℃ to 70 ℃

Storage Temperature

- 45 ℃ to 85 ℃

Humidity

Operating

0% to 95% (Non-condensing)

Non-Operating

0% to 95% (Non-condensing)

Performance

Model P/N

Sequential

Read*

Sequential

Write*

Random

Read

(4KB QD32)*

Random

Write

(4KB QD32)*

IOPS

Random Read

(4KB QD32)**

IOPS

Random Write

(4KB QD32)**

TS128GMSM360

514.1

160.4

117.5

156.4

32743

38150

Reliability

Data Reliability

Supports BCH ECC 66 bits per 1K byte

MTBF

1,000,000 hours

Endurance (Terabytes Written)

128G

TBT

Regulations

Compliance

CE, FCC and BSMI
